Improved Durability with top quality manufactured insulation ensuring full compliance with industry standards, designed to withstand extreme temperatures, moisture and physical harms
RRH Cable we have the capability to manufacture grade A 99.9% pure copper precisely stranded in the insulators for the best conductivity and efficiency
Thanks to our expert craftsmanship, we provide high-quality cables that minimize the need for frequent maintenance or replacements, significantly reducing long-term operational costs.
| Parameter | Specification |
| Rated Voltage | 600/1000 V AC |
| Conductor Material | Stranded Annealed Copper |
| Insulation Material | XLPE (Cross-linked Polyethylene), UV & heat resistant |
| Sheath Material | PVC or LSZH (Low Smoke Zero Halogen), UV and weather resistant |
| Core Type | Single-core and Multi-core (2, 3, 4, 5 core available) |
| Operating Temp Range | -40°C to +90°C continuous; +120°C short circuit (max. 5s) |
| UV Resistance | Yes (suitable for outdoor installations) |
| Cross Section (mm²) | AWG | Conductor Ø(mm) | Outer Diameter (mm) | Ampacity (A) @ 30°C (air) |
| 1.5 mm² | 16 AWG | ~1.4 mm | ~5.0 - 6.0 mm | 18 - 20 A |
| 2.5 mآ⊃2; | 14 AWG | ~1.8 mm | ~6.0 - 7.0 mm | 25 - 30 A |
| 4 mm² | 12 AWG | ~2.2 mm | ~7.0 - 8.0 mm | 35 - 41 A |
| 6 mm² | 10 AWG | ~2.6 mm | ~8.0 - 9.0 mm | 44 - 55 A |
| 10 mm² | 8 AWG | ~3.6 mm | ~9.0 - 10.5 mm | 65 - 75 A |
| 16 mm² | 6 AWG | ~4.5 mm | ~10.5 - 12.0 mm | 85 - 100 A |
| 25 mm² | 4 AWG | ~5.6 mm | ~12.5 - 14.0 mm | 115 - 135 A |
| 35 mm² | 2 AWG | ~6.7 mm | ~14.5 - 16.0 mm | 135 - 170 A |
| 50 mm² | 1 AWG | ~7.8 mm | ~16.0 - 18.0 mm | 160 - 200 A |
| 70 mm² | 2/0 AWG | ~9.5 mm | ~18.0 - 20.0 mm | 200 - 250 A |
| 95 mm² | 3/0 AWG | ~11.0 mm | ~20.0 - 22.5 mm | 240 - 290 A |
| 120 mm² | 4/0 AWG | ~12.5 mm | ~22.5 - 25.0 mm | 280 - 320 A |
| 150 mm² | -- | ~13.8 mm | ~24.0 - 26.5 mm | 320 - 350 A |
| 185 mm² | -- | ~15.5 mm | ~26.5 - 29.0 mm | 350 - 400 A |
| 240 mm² | -- | ~17.5 mm | ~29.0 - 32.0 mm | 400 - 450 A |
Inverter to distribution panel transmits converted AC power to the main electrical distribution system
Inverter to Transformer or grid to send AC power to grid connection points or transformers
Connection between Inverters, linking multiple inverters or combines AC outputs in larger systems
Apply cable base on its insulation property
Avoid bends
Always de-energize the system before working on cables
Proper PPE duing operation
| Feature | Why It Matters |
| High Voltage Rating (0.6/1 kV) | Ensures safe and efficient power transmission from inverter to grid/load. |
| Stranded Copper Conductor | Provides superior conductivity and flexibility for easier installation. |
| XLPE Insulation (Cross-Linked PE) | Resists high temperatures, electrical stress, and aging – increases lifespan. |
| UV & Weather Resistance | Suitable for outdoor use – resists sunlight, moisture, and environmental damage. |
| Flame Retardant | Reduces fire hazards and complies with IEC 60332 standards. |
| Low Smoke, Halogen-Free (LSZH) | Increases safety in enclosed or populated areas during fire – emits low smoke. |
| Single and Multi-Core Options | Provides installation flexibility across residential, commercial, and utility use. |
| Wide Temperature Range (-40°C to +90°C) | Operates safely in extreme climate conditions. |
| Oil & Chemical Resistance (optional) | Withstands industrial environments – ensures long-term performance. |
| Color-Coded Insulation | Simplifies phase identification and safe connections during installation. |
