Improved Durability with top quality manufactured insulation ensuring full compliance with industry standards, designed to withstand extreme temperatures, moisture and physical harms
RRH Cable we have the capability to manufacture grade A 99.9% pure copper precisely stranded in the insulators for the best conductivity and efficiency
Thanks to our expert craftsmanship, we provide high-quality cables that minimize the need for frequent maintenance or replacements, significantly reducing long-term operational costs.
| AWG Size | Conductor Area (mm²) | Voltage Rating | Current Rating (Ampacity) | Insulation Type | Conductor Material | Core Type | Typical No. of Conductors | Use Cases / Sensor Types |
| 30 AWG | 0.05 mm² | 30 – 60V | 0.5 – 1.0 A | PVC / FEP / TPE | Tinned Copper | Stranded (7x finer) | 2 – 10 | Compact digital sensors, embedded sensing in electronics |
| 28 AWG | 0.08 mm² | 30 – 100V | 0.8 – 1.4 A | PVC / TPE / FEP | Tinned Copper | Stranded | 2 – 12 | Proximity sensors, I2C, UART, SPI, analog sensors |
| 26 AWG | 0.13 mm² | 100 – 300V | 1.0 – 2.2 A | PVC / PUR / FEP | Tinned Copper | Stranded | 2 – 20 | Pressure, temperature sensors, CAN bus nodes |
| 24 AWG | 0.20 mm² | 100 – 300V | 2.0 – 3.5 A | PVC / PE / XLPE | Bare / Tinned Copper | Stranded | 2 – 24 | RS-485, 3-wire and 4-wire sensors |
| 22 AWG | 0.34 mm² | 300V | 3.5 – 5.5 A | PVC / PE / FEP | Bare / Tinned Copper | Stranded / Solid | 2 – 30 | Analog sensors, encoders, thermocouples |
| 20 AWG | 0.52 mm² | 300V | 5 – 8 A | PVC / XLPE / TPE | Bare / Tinned Copper | Stranded | 2 – 30 | Optical sensors, strain gauges, analog/digital combo |
| 18 AWG | 0.82 mm² | 300 – 600V | 7 – 12 A | PVC / TPE / Silicone | Bare / Tinned Copper | Stranded | 2 – 25 | Load cells, powered sensor arrays |
| 16 AWG | 1.3 mm² | 300 – 600V | 10 – 15 A | PVC / Silicone / FEP | Bare / Tinned Copper | Stranded | 2 – 15 | Actuated sensors, sensors with higher current draw |
Automotive, engine control harness, ABC, airbag system etc
Industrial Automation, conveyor systems, CNC machines, robotic arms etc
Medical Devices, monitoring devices, diagnostics equipment etc
Home Apppliances, smart phone device, mobile phones , connected devices etc
Agriculture & Heavy Equipment, harvesters, drones, tractors etc
Apply cable base on its insulation property
Avoid bends
Always de-energize the system before working on cables
Proper PPE duing operation
| Key Feature | Why It’s Important |
| Shielded Cable | Prevents EMI that can corrupt sensitive analog/digital sensor signals |
| Flexible Insulation | Allows dynamic movement without cable fatigue |
| Miniature Connectors | Saves space in tight assemblies |
| Color-coded Wires | Easier field service and maintenance |
| High Signal Integrity | Ensures accurate readings from sensors |
| Quick Connect Interfaces | Speeds up sensor changeover and service time |
