Improved Durability with top quality manufactured insulation ensuring full compliance with industry standards, designed to withstand extreme temperatures, moisture and physical harms
RRH Cable we have the capability to manufacture grade A 99.9% pure copper precisely stranded in the insulators for the best conductivity and efficiency
Thanks to our expert craftsmanship, we provide high-quality cables that minimize the need for frequent maintenance or replacements, significantly reducing long-term operational costs.
| Cable Type | AWG Size | mm² | Voltage Rating | Ampacity | Insulation Type | Conductor Material | Core Type | No. of Conductors | Shielding |
| Type G-GC | 8 – 500 MCM | 8.37 – 253 | 600V – 2kV | 40 – 600 A | EPR / CPE | Tinned / Annealed Copper | Stranded | 3 or 4 + ground | Grounding conductor |
| Type W | 8 – 500 MCM | 8.37 – 253 | 2000V | 40 – 600 A | EPR / CPE | Annealed Copper | Extra-flex Stranded | 1–5 | Optional |
| Type SHD-GC | 4 – 500 MCM | 21.15 – 253 | 5kV – 25kV | 80 – 600 A | XLPE / EPR | Tinned Copper | Stranded | 3 + ground | Shielded, tape + braid |
| Type G | 8 – 500 MCM | 8.37 – 253 | 600V – 2kV | 40 – 600 A | EPR / CPE | Tinned Copper | Stranded | 4 | Ground optional |
| Portable Mining Cable | 2 – 500 MCM | 33.62 – 253 | 600V – 15kV | 95 – 600 A | Chlorinated Polyethylene (CPE), Rubber | Tinned Copper | Extra-flex Stranded | 1 – 5 | Optional braid |
| MV Mining Cable | 1/0 – 500 MCM | 53.48 – 253 | 5kV – 35kV | 150 – 600 A | EPR / XLPE | Copper / Tinned Copper | Stranded | 3 or 3+1 (ground) | Full copper shield |
There's heavy EMI from motors, drives, or transformers
Signal accuracy and low data loss are critical
Long cable runs pass near power lines or switching equipment
You're wiring audio/video systems, medical instruments, or precision sensors
Industrial Automation Transmit control signals between PLCs, sensors, and motors
Medical Equipment Carry high-fidelity signals for sensitive diagnostic tools and monitors
Broadcast & AV Systems Prevent noise in video/audio signal transmission over long distances
Military & Aerospace Secure and stable communication in high-EMI environments
Telecom & Networking Ensure stable, high-speed data transfer (e.g., Cat6a STP Ethernet)
Data Centers Eliminate crosstalk and EMI from adjacent power cables
Railway & Transportation Systems Reliable communication amidst high voltage and vibration
Measurement Systems Transmit low-voltage, analog/digital signals with high accuracy
Apply cable base on its insulation property
Always de-energize the system before working on cables
Proper PPE duing operation
| Challenge | Mining Cable Solution |
| Abrasion & Impact | Thick, reinforced outer sheaths (often TPU, CPE, or rubber) |
| Moisture & Water Ingress | Water-blocking tapes and compounds, tight jacketing |
| Flexing & Movement | High-flex stranded conductors and flexible rubber insulation |
| Oil, Mud & Chemical Resistance | Outer sheath materials resist fuels, lubricants, and acids |
| High Voltage Requirements | Rated for up to 35kV for large-scale power transmission |
