| Quantity: | |
|---|---|
Improved Durability with top quality manufactured insulation ensuring full compliance with industry standards, designed to withstand extreme temperatures, moisture and physical harms
RRH Cable we have the capability to manufacture grade A 99.9% pure copper precisely stranded in the insulators for the best conductivity and efficiency
Thanks to our expert craftsmanship, we provide high-quality cables that minimize the need for frequent maintenance or replacements, significantly reducing long-term operational costs.
| Cable Type | AWG Size | Cross-Section (mm²) | No. of Conductors | Voltage (V) | Ampacity (A) | Insulation | Conductor Material | Core Type | Shielding |
| CAN Bus | 20 AWG | 0.52 mm² | 2 | 12 – 24 | 5 | XLPE / FEP | Tinned Copper | Stranded | Twisted Pair + Foil |
| Ethernet Cat5e | 24 AWG | 0.205 mm² | 8 (4 pairs) | 48 (PoE) | ~0.5 | PE / PVC / LSZH | Bare/Tinned Copper | Solid / Stranded | UTP / FTP / STP |
| Ethernet Cat6 | 23 AWG | 0.258 mm² | 8 (4 pairs) | 48 (PoE+) | ~0.577 | HDPE / LSZH | Bare Copper | Solid / Stranded | UTP / STP |
| USB 2.0 | 28 AWG (Data) | 0.081 mm² (Data) | 4 | 5 | 0.5 – 2.5 | PVC / TPE | Tinned Copper | Stranded | Foil + Braid |
| 24 AWG (Power) | 0.205 mm² (Power) | ||||||||
| USB 3.0 | 28 AWG (Data) | 0.081 mm² (Data) | 9 | 5 | Up to 3 | XLPE / PVC | Tinned Copper | Stranded | Multiple Foils + Braid |
| 20 AWG (Power) | 0.52 mm² (Power) | ||||||||
| HDMI | 30 – 28 AWG | 0.05 – 0.081 mm² | 19 | 5 | <1 | PE / LSZH | Tinned Copper | Stranded | Multiple Foils |
| Coaxial (RG58) | 20 AWG | 0.52 mm² (core) | 1 | Up to 500 | ~2 | PE / PVC | Solid / Stranded Copper | Solid / Stranded | Braided Shield |
Automotive, local interconnect network, ethernet cable, driver assistance system, etc
Industrial Automation, modbus, devicenet, data terminal equipments, etc
Networking, fiber optic cable, etc
Medical Equipment, data cables for imaging, sensors, diagnostics, etc
Apply cable base on its insulation property
Always de-energize the system before working on cables
Proper PPE duing operation
| Feature | Importance |
| Shielding (Foil/Braid) | Prevents electromagnetic interference (EMI) and signal crosstalk |
| Twisted Pair Design | Minimizes noise and supports high-speed differential signaling |
| Impedance Control | Maintains signal integrity in high-frequency or long-distance applications |
| Flexibility | Allows routing in tight spaces or moving assemblies |
| Low Capacitance | Essential for high-speed data transmission |
| Durability | Must resist vibration, bending, heat, and chemicals (especially in vehicles) |
| LSZH Insulation | Low-smoke, zero halogen; used in confined areas like trains, ships, or server rooms |
